•Housing Material: Aluminum
•Mounting Bracket: Stainless steel
•Lens Material: PC
•Color Temperature: 6000K-6500K
•Beam Pattern: Driving + Position
•Waterproof & Dustproof:IP67
•Over-heated protected
•Lifespan:≥50000hrs
| PRODUCT SPECIFICATION： | |||||||||
| ITEM NO. | SIZE | POWER | LED QTY | OPERATING VOLTAGE | LED COLOR TEMPERATURE | LIFESPAN | LUMINOUS FLUX | WATER(DUST)PROOF | |
| PL7406GH | 14" | 45W | Driving 6PCS | Position Light 21Pcs | 10-30V | 6500K | 50000hrs | 4000-4500LM | IP67 |
| PL7407GH | 22" | 75W | Driving 10PCS | Position Light 36Pcs | 10-30V | 6500K | 50000hrs | 6000-6500LM | IP67 |
| PL7408GH | 32" | 120W | Driving 16PCS | Position Light 48Pcs | 10-30V | 6500K | 50000hrs | 9500-10000LM | IP67 |
| PL7409GH | 42" | 150W | Driving 20PCS | Position Light 60Pcs | 10-30V | 6500K | 50000hrs | 11500-12500LM | IP67 |
| PL7410GH | 52" | 180W | Driving 24PCS | Position Light 72Pcs | 10-30V | 6500K | 50000hrs | 11500-12500LM | IP67 |
